Mainshaft Disassembly, Inspection, and Reassembly

WARNING: This page is about a different car, the 2013 Honda Fit, 2012 Honda Fit, 2011 Honda Fit, 2010 Honda Fit, and 2009 Honda Fit. However, it is still accessible from the selected car via links, so may be relevant.

Inspect the thrust needle bearings and the needle bearings for galling and rough movement.

Fig 1: Inspecting Thrust Needle Bearings And Needle Bearings With Torque Specifications
Courtesy of AMERICAN HONDA MOTOR CO., INC.
Inspect the splines for excessive wear and damage.
Check the shaft bearing surfaces for scoring and excessive wear.
Before installing the O-rings, wrap the shaft splines with tape to prevent O-ring damage.
Lubricate all parts with ATF during assembly.
Install the conical spring washer and the 40 x 63 mm thrust washer in the direction shown.
Replace the locknut and the conical spring washer with new ones when assembling the transmission.
Check the axial clearance of 3rd gear (see MAINSHAFT 3RD GEAR AXIAL CLEARANCE INSPECTION ).
