Rear Undercover Replacement

WARNING: This page is about a different car, the 2013 Honda Fit, 2012 Honda Fit, 2011 Honda Fit, 2010 Honda Fit, and 2009 Honda Fit. However, it is still accessible from the selected car via links, so may be relevant.

NOTE:

Put on gloves to protect your hands.
Take care not to scratch the rear bumper or the body.

Remove the bolts (A) and the clips (B, C) that secure the rear undercover (D) and the rear bumper (E) to the body, then remove the undercover.
NOTE: To release the clips, pry up on the center pin at the notch (F).

Fig 1: Rear Undercover, Rear Bumper, Bolts & Clips With Torque Specifications
Courtesy of AMERICAN HONDA MOTOR CO., INC.
Install the undercover in the reverse order of removal, and note these items:
- If the clips are damaged or stress-whitened, replace them with new ones.
- Push the clips into place securely.
