Beverage Holder Removal/Installation

WARNING: This page is about a different car, the 2013 Honda Fit, 2012 Honda Fit, 2011 Honda Fit, 2010 Honda Fit, and 2009 Honda Fit. However, it is still accessible from the selected car via links, so may be relevant.

NOTE:

Put on gloves to protect your hands.
Take care not to scratch the dashboard or its related parts.

Remove the dashboard/steering hanger beam (see DASHBOARD/STEERING HANGER BEAM REMOVAL/INSTALLATION ).
Remove the screws, then remove the beverage holders (A) from both ends of the dashboard (B).

Fig 1: Identifying Beverage Holders & Dashboard
Courtesy of AMERICAN HONDA MOTOR CO., INC.
Install the beverage holders in the reverse order of removal.
