Rear Door Sash Outer Trim Replacement

WARNING: This page is about a different car, the 2013 Acura MDX, 2012 Acura MDX, 2011 Acura MDX, and 2010 Acura MDX. However, it is still accessible from the selected car via links, so may be relevant.

NOTE: Take care not to scratch the door.

Lower the glass fully.
Using a clip remover, detach the clips fastening the door weatherstrip (A) from the door sash outer trim (B).

Fig 1: Detaching Clips Fastening Door Weatherstrip From Door Sash Outer Trim
Courtesy of AMERICAN HONDA MOTOR CO., INC.
Remove the door sash outer trim (A).
1. Pull back the door weatherstrip (B), then remove the screw.
2. Pull the trim up to release the hooks (C) from the door. Take care not to damage the door glass outer weatherstrip (D).
Fig 2: Pulling Back Door Weatherstrip And Screw
Courtesy of AMERICAN HONDA MOTOR CO., INC.
Install the trim in the reverse order of removal, and note these items:
- Make sure the glass run channel (E) is installed in the door sash securely.
- If the clips are damaged or stress-whitened, replace them with new ones.
- Push the clips into place securely.
