ENGINE COOLANT TEMPERATURE GAUGE: Component Parts Location

Fig 1: Identifying Engine Coolant Temperature Gauge Component Parts Location (1 Of 2)

Courtesy of NISSAN NORTH AMERICA, INC.

Fig 2: Identifying Engine Coolant Temperature Gauge Component Parts Location (2 Of 2)

Courtesy of NISSAN NORTH AMERICA, INC.
