SHIFT POSITION INDICATOR : Component Parts Location
SHIFT POSITION INDICATOR : Component Parts Location
Fig 1: Identifying Shift Position Indicator Component Parts Location
Courtesy of NISSAN MOTOR CO., U.S.A.
Courtesy of NISSAN MOTOR CO., U.S.A.
