Disassembly and Assembly: Disassembly

WARNING: This page is about a different variant/trim than selected.
  1. Remove clevis and push rod lock nut from push rod.
  2. Remove boot from master cylinder.
  3. Remove stopper ring from master cylinder while holding push rod.
  4. Remove push rod, piston, and return spring from master cylinder.
    Fig 1: Identifying Push Rod, Piston And Return Spring
    G05224224Courtesy of NISSAN MOTOR CO., U.S.A.
