Section 5 (Engine Lubrication System (Qr25DE))
>>
Lubrication System
>>
System Drawing
System Drawing
WARNING:
This page is about a different variant/trim than selected.
Fig 1: System Drawing
Courtesy of NISSAN MOTOR CO., U.S.A.
