(D) Combination Switch

WARNING: This page is about a different car, the 2004 Infiniti G35. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove bolts of cluster lid A.
    Fig 1: Removing Bolts Of Cluster Lid A
    G00733748Courtesy of NISSAN MOTOR CO., U.S.A.
  2. Remove pawl on upper and lower of combination switch.
  3. Disconnect harness connector of wiper washer switch.
  4. Use cloth to protect cluster lid A and combination switch from damage. Remove combination switch through gap between cluster lid A and steering wheel.
