18. A/T Does Not Shift: 33 --> 22, When Selector Lever 3 --> 2 Position

SYMPTOM:

A/T does not shift from 33 to 22 when changing selector lever from 3 to 2 position.

1. CHECK PARK/NEUTRAL POSITION (PNP) SWITCH CIRCUIT

   With CONSULT-II

   Does "TCM INPUT SIGNALS" in "DATA MONITOR" show damage to park/neutral position (PNP) switch circuit?

   Without CONSULT-II

   Does self-diagnosis show damage to park/neutral position (PNP) switch circuit?

   Yes or No

   1. Yes: Check park/neutral position (PNP) switch circuit. Refer to "DTC P0705 PARK/NEUTRAL POSITION SWITCH ".
   2. No: Go to "9. A/T DOES NOT SHIFT: D1 --> D2 OR DOES NOT KICKDOWN: D4 --> D2 ".
      Fig 1: PNP Switch Circuit (Selector Lever 3 --> 2 Position) Self-Diagnosis

      Courtesy of NISSAN MOTOR CO., U.S.A.
