Removal and Installation: Removal

WARNING: This page is about a different car, the 2009 Nissan Maxima. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the steering column cover (1). Refer to "REMOVAL AND INSTALLATION ".
  2. Press pawls and remove tilt & telescopic switch (2) from the steering column mask (1).
Fig 1: Identifying Steering Column Cover And Tilt & Telescopic Switch
G05877725Courtesy of NISSAN MOTOR CO., U.S.A.
