Component Parts and Harness Connector Location

WARNING: This page is about a different car, the 2007 Nissan Pathfinder. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Headlamp Component Parts And Harness Connector Location (For Canada)
G04913789
