Removal and Installation of Hood Assembly

WARNING: This page is about a different car, the 2007 Nissan Pathfinder. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Exploded View Of Hood Assembly
G04895639
  1. Support the hood striker with suitable tool to prevent it from falling.
  2. Remove the hinge nuts from the hood to remove the hood assembly.
CAUTION: Operate with two workers, because of its heavy weight.

Installation is in the reverse order of removal.
