Removal and Installation of Rear Tweeter: Removal

WARNING: This page is about a different car, the 2012 Nissan Pathfinder. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove rear door finisher. Refer to "REMOVAL AND INSTALLATION ".
  2. Remove the rear tweeter screws (A) and remove the rear tweeter (1).
Fig 1: Identifying Rear Tweeter And Screws
G08170009Courtesy of NISSAN NORTH AMERICA, INC.
