Diagnosis Procedure

WARNING: This page is about a different car, the 2009 Nissan Maxima. However, it is still accessible from the selected car via links, so may be relevant.
  1. CHECK UNLOCK SENSOR POWER SUPPLY

    Check signal between BCM connector and ground with oscilloscope.

    Fig 1: Checking Signal Between BCM Connector And Ground With Oscilloscope
    G05046404G04888175Courtesy of NISSAN MOTOR CO., U.S.A.NISSAN MOTOR CO., U.S.A.
    VOLTAGE SPECIFICATION

    Terminals Front door lock assembly LH condition Voltage (V) (Approx.)
    (+) (-)
    BCM connector Terminal
    M18 27 Ground Locked
    G04888175Courtesy of NISSAN MOTOR CO., U.S.A.
    Unlocked 0

    Is the inspection result normal?

    YES: GO TO  6

    NO: GO TO 2

  2. CHECK UNLOCK SENSOR CIRCUIT
    1. Turn ignition switch OFF.
    2. Disconnect BCM and front door lock assembly LH connector.
    3. Check continuity between BCM connector and front door lock assembly LH connector.
      CONTINUITY CHART

      BCM connector Terminal Front door lock assembly LH connector Terminal Continuity
      A: M18 27 B: D10 3 Yes
    4. Check continuity between BCM connector and ground.
      CONTINUITY CHART

      BCM connector Terminal Ground Continuity
      A: M18 27 No
      Fig 2: Checking Continuity Between BCM Connector And Ground
      G05046406Courtesy of NISSAN MOTOR CO., U.S.A.

      Is the inspection result normal?

      YES: GO TO 3

      NO: Repair or replace harness between BCM and front door lock assembly LH.

  3. CHECK UNLOCK SENSOR GROUND CIRCUIT

    Check continuity between front door lock assembly LH connector and ground.

    CONTINUITY CHART

    Front door lock assembly LH connector Terminal Ground Continuity
    D10 4 Yes
    Fig 3: Checking Continuity Between Front Door Lock Assembly LH Connector And Ground
    G05046830Courtesy of NISSAN MOTOR CO., U.S.A.

    Is the inspection result normal?

    YES: GO TO 4

    NO: Repair or replace harness.

  4. CHECK BCM OUTPUT SIGNAL
    1. Connect BCM harness connector.
    2. Check signal between BCM connector and ground with oscilloscope.
    VOLTAGE SPECIFICATION

    Terminals Voltage (V) (Approx.)
    (+) (-)
    BCM connector Terminal
    M18 27 Ground
    G04888175Courtesy of NISSAN MOTOR CO., U.S.A.
    Fig 4: Checking Signal Between BCM Connector And Ground With Oscilloscope
    G05046408Courtesy of NISSAN MOTOR CO., U.S.A.

    Is the inspection result normal?

    YES: GO TO 5

    NO: Replace BCM. Refer to "REMOVAL AND INSTALLATION "

  5. CHECK UNLOCK SENSOR

    Refer to "COMPONENT INSPECTION ".

    Is the inspection result normal?

    YES: GO TO 6

    NO: Replace front door lock assembly LH. Refer to "FRONT DOOR LOCK: REMOVAL AND INSTALLATION ".

  6. CHECK INTERMITTENT INCIDENT

    Refer to "INTERMITTENT INCIDENT ".

    Inspection End.
