Removal and Installation LH: Installation

WARNING: This page is about a different car, the 2009 Nissan Maxima. However, it is still accessible from the selected car via links, so may be relevant.

Installation is in the reverse order of removal.

Apply sealant to the areas on the front corners using Tool.

Fig 1: Identifying Liquid Gasket Location
Courtesy of NISSAN MOTOR CO., U.S.A.
Use Genuine Silicone RTV Sealant or equivalent. Refer to "RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS ".
Tool number: WS39930000 (-)
Tighten the rocker cover bolts in two steps in the order as shown.

Fig 2: Identifying Tightening Sequence Of Rocker Cover Bolts
Courtesy of NISSAN MOTOR CO., U.S.A.

Rocker cover bolts

Step 1: 1.96 N.m (0.20 kg-m, 17 in-lb)

Step 2: 8.33 N.m (0.85 kg-m, 74 in-lb)
