Diagnostic Procedure

WARNING: This page is about a different car, the 2003 Nissan Pathfinder. However, it is still accessible from the selected car via links, so may be relevant.

CHECK CAN COMMUNICATION CIRCUIT
With CONSULT-II
1. Turn ignition switch to "ON" position. (Do not start engine.)
2. Select "SELF-DIAG RESULTS" mode for "A/T" with CONSULT-II.
3. The "CAN COMM CIRCUIT" is detected.
Fig 1: CONSULT- II (Self Diag Results)
Courtesy of NISSAN MOTOR CO., U.S.A.

Yes or No?
1. Yes: Print out CONSULT-II screen, go to "CAN Communication Unit ".
2. No: INSPECTION END
