Relation Between Shift Solenoid Valves A and B and Gear Positions

WARNING: This page is about a different car, the 2002 Nissan Sentra. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Solenoid A & B Positions

Courtesy of NISSAN MOTOR CO., U.S.A.
