Self-Diagnostic Procedure (With Consult-II)

WARNING: This page is about a different car, the 2002 Nissan Sentra. However, it is still accessible from the selected car via links, so may be relevant.

Turn on CONSULT-II and touch ENGINE for OBD-II detected items or touch A/T for TCM self-diagnosis. See Figure.
If A/T is not displayed, check TCM power supply and ground circuit. Refer to TROUBLE DIAGNOSIS FOR POWER SUPPLY . If result is NG, Refer to POWER DISTRIBUTION .
Touch SELF DIAG RESULTS.

Fig 1: Displaying REAL-TIME DIAG RESULTS On CONSULT-II
Courtesy of NISSAN MOTOR CO., U.S.A.

Display shows malfunction experienced since the last erasing operation.

CONSULT-II performs REAL TIME DIAG.

Also, any malfunction detected while in this mode will be displayed at real time.
