Clutch Cover And Flywheel

WARNING: This page is about a different car, the 2002 Nissan Sentra. However, it is still accessible from the selected car via links, so may be relevant.

Check clutch cover installed on vehicle for unevenness of diaphragm spring too height.

Fig 1: Determining Diaphragm Spring Toe Height
Courtesy of NISSAN MOTOR CO., U.S.A.
1. Uneven limit : 0.88 mm (0.0346 in)
If out of limit, adjust the height with Tool.
