Power Supply and Ground Circuit for Auto Amp.: Notes

WARNING: This page is about a different car, the 2004 Nissan Maxima. However, it is still accessible from the selected car via links, so may be relevant.

SYMPTOM: A/C system does not come on. Refer to Fig 1.

Fig 1: Power Supply And Ground Circuit For Auto Amp. Diagnostic Flow Chart

Courtesy of NISSAN MOTOR CO., U.S.A.
