Inspection Flow

WARNING: This page is about a different car, the 2004 Nissan Maxima. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Intake Door Motor Circuit Inspection Flow Chart
G00341012Courtesy of NISSAN MOTOR CO., U.S.A.
