Rear Washer Tube Layout

WARNING: This page is about a different car, the 2012 Nissan Pathfinder. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Layout Of Rear Washer Tube

Courtesy of NISSAN NORTH AMERICA, INC.

NOTE: Connect the check valve (2) to the washer fluid tube (1) so that the directional arrow on the check valve (2) points towards the washer nozzle tube (3).
