Removal and Installation of Rear Oil Seal: Removal

WARNING: This page is about a different car, the 2008 Nissan Maxima. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the transaxle. Refer to "TRANSAXLE ASSEMBLY ".
  2. Remove the transaxle. Refer to REMOVAL AND INSTALLATION .
  3. Remove drive plate (CVT).
  4. Remove rear oil seal using a suitable tool.
    CAUTION:
    • Be careful not to damage crankshaft and cylinder block.
    • If rear oil retainer is removed, replace it with a new one
    Fig 1: Removing Rear Oil Seal Retainer
    G04080053Courtesy of NISSAN MOTOR CO., U.S.A.
