Checking SRS Operation Using "AIR BAG" Warning Lamp-User Mode

WARNING: This page is about a different car, the 2005 Nissan Quest. However, it is still accessible from the selected car via links, so may be relevant.
  1. Turn the ignition switch from OFF to ON, and check that the air bag warning lamp blinks.
  2. Compare the SRS air bag warning lamp blinking pattern with the examples.
    Fig 1: Checking SRS Operation
    G02447886Courtesy of NISSAN MOTOR CO., U.S.A.
