Fluid Condition Check

WARNING: This page is about a different car, the 2005 Nissan Quest. However, it is still accessible from the selected car via links, so may be relevant.
FLUID CONDITION SPECIFICATION TABLE

Fluid status Conceivable Cause Required Operation
Varnished (viscous varnish state) Clutch, brake scorched Replace the A/T fluid and check the A/T main unit and the vehicle for malfunctions (wire harnesses, cooler pipes, etc.)
Milky white or cloudy Water in the fluid Replace the A/T fluid and check for places where water is getting in.
Large amount of metal powder mixed in Unusual wear of sliding parts within A/T Replace the A/T fluid and check for improper operation of the A/T.
Fig 1: Checking Fluid Condition
G02447237Courtesy of NISSAN MOTOR CO., U.S.A.
