Removal and Installation for Washer Tank

WARNING: This page is about a different car, the 2004 Nissan Maxima. However, it is still accessible from the selected car via links, so may be relevant.

Pull out washer tank inlet.
Remove fender protector, refer to REMOVAL AND INSTALLATION . "Removal and Installation".
Remove front washer motor connector and washer fluid level switch connector.
Remove washer tank screws.
Remove washer hose, and remove the washer tank from the vehicle.

Fig 1: Removing Washer Tank Screws

Courtesy of NISSAN MOTOR CO., U.S.A.

CAUTION: After installation, add water up to the upper level of the washer tank inlet, and check for water leaks.

Washer tank installation screw

Tightening torque: 3.9 - 5.0 N.m (0.40 - 0.50 kg-m, 34 - 45 in-lb)
