Wiring Diagram --TRNSCV--

WARNING: This page is about a different car, the 2004 Nissan Maxima. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Integrated Homelink Transmitter - Wiring Diagram & Identifying Connectors - BL-TRNSCV-01

Courtesy of NISSAN MOTOR CO., U.S.A.
