Section 1172 (Manual Transaxle - RS5F70A)
>>
Service Data And Specifications (SDS)
>>
Available Thrust Washer
>>
MAINSHAFT Thrust Washer
MAINSHAFT Thrust Washer
WARNING:
This page is about a different car, the 2004 Nissan Sentra. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Mainshaft Thrust Washer Specifications
Courtesy of NISSAN MOTOR CO., U.S.A.
