NVH Troubleshooting Chart

WARNING: This page is about a different car, the 2004 Nissan Sentra. However, it is still accessible from the selected car via links, so may be relevant.

Use the chart below to help you find the cause of the symptom. The numbers indicate the order of inspection.

Check each part in order. If necessary, repair or replace these parts.

Fig 1: Noise, Vibration, And Harshness (NVH) Troubleshooting Chart
G00777128Courtesy of NISSAN MOTOR CO., U.S.A.
