With Consult-II

WARNING: This page is about a different car, the 2004 Nissan Quest. However, it is still accessible from the selected car via links, so may be relevant.

Turn ignition switch "ON". (Do not start engine.)
Select "DATA MONITOR" mode for "TRANSMISSION" with CONSULT-II.
Start engine.
Drive vehicle and check for an increase of "VHCL/S SE-A/T" value in response to "VHCL/S SE-MTR" value.
If the check result is NG, go to "DIAGNOSTIC PROCEDURE ". If the check result is OK, go to following step.
Maintain the following conditions for at least 2 consecutive minutes.

Fig 1: CONSULT-II Screen Display - TRANSMISSION
Courtesy of NISSAN MOTOR CO., U.S.A.

FLUID TEMP: More than 20°C (68°F)

VHCL/S SE-A/T: 70 km/h (43 MPH) or more

SLCT LVR POSI: "D" position

If the check result is NG, go to "DIAGNOSTIC PROCEDURE ".
