Engine Cannot Be Started in P and N Position

SYMPTOM:

• Engine cannot be started with selector lever in P or N position  .
• Engine can be started with selector lever in D, L or R position  .

1. CHECK PARK/NEUTRAL POSITION (PNP) SWITCH CIRCUIT

   With CONSULT-II

   Does "DATA MONITOR" show damage to park/neutral position (PNP) switch circuit?

   Without CONSULT-II

   Does self-diagnosis show damage to park/neutral position (PNP) switch circuit?

   Fig 1: Checking Park/Neutral Position (PNP) Switch Circuit

   Courtesy of NISSAN MOTOR CO., U.S.A.

   Yes or No

   1. Yes: Check park/neutral position (PNP) switch circuit. Refer to "DTC P0705 PARK/NEUTRAL POSITION SWITCH ".
   2. No: GO TO 2.
2. CHECK PARK/NEUTRAL POSITION (PNP) SWITCH

   Check for short or open of park/neutral position (PNP) switch harness connector F29 terminals 1 (G/R) and 2(G). Refer to "WIRING DIAGRAM - AT-PNP/SW ".

   OK or NG

   1. OK: GO TO 3.
   2. NG: Repair or replace park/neutral position (PNP) switch.
3. ADJUST CONTROL CABLE

   Check control cable. Refer to "CONTROL CABLE ADJUSTMENT "

   Fig 2: Adjusting Control Cable

   Courtesy of NISSAN MOTOR CO., U.S.A.

   OK or NG

   1. OK: GO TO 4.
   2. NG: Adjust control cable. Refer to "CONTROL CABLE ADJUSTMENT ".
4. CHECK STARTING SYSTEM

   Check starting system. Refer to TROUBLE DIAGNOSES WITH BATTERY/STARTING/CHARG .

   OK or NG

   1. OK: INSPECTION END
   2. NG: Repair or replace damaged parts.
