Piston and Piston Pin Interference Fit
WARNING: This page is about a different car, the 2004 Nissan Quest. However, it is still accessible from the selected car via links, so may be relevant.
Standard Interference Fit = Dp - dp"
- Standard: 0.002 mm - 0.006 mm (0.0001 - 0.0002 in)
- If clearance is exceeds specification, replace either or both of piston/piston pin assembly and connecting rod assembly with reference to specification of each part.
- When replacing piston/piston pin assembly, refer to PISTON-TO-CYLINDER BORE CLEARANCE .
