Home >> Nissan-Datsun >> 1994 >> Sentra (4 Door) L4-1597cc 1.6L DOHC MFI (GA16DE) >> Repair and Diagnosis >> Locations >> Connector Locations >> B Connectors, Body >> B-101 Thru B-103

B-101 Thru B-103

Body Harness - 4-door Sedan (USA):
