Exhaust Manifold: Service and Repair

1. Disconnect battery ground cable.
2. Remove exhaust pipe to exhaust manifold attaching nuts.

Fig. 4 Outer Components (Part 1 Of 2):

3. Disconnect any vacuum hoses or electrical connectors that interfere with manifold removal, Fig. 4. Mark hoses and connectors for installation reference.
4. Remove A/C compressor from its bracket and position aside. Do not disconnect refrigerant lines.
5. Remove alternator from its bracket and position aside.
6. Remove compressor and alternator brackets.

Fig. 7 Exhaust Manifold Bolt Loosening Sequence:

7. Using sequence shown in Fig. 8, remove exhaust manifold attaching bolts.
8. Remove manifolds from engine.

Fig. 8 Exhaust Manifold Tightening Sequence:

9. Reverse procedure to install. Tighten manifold attaching bolts to specifications using sequence shown in Fig. 10.
