NX L4-1597cc 1.6L DOHC MFI (GA16DE)
>>
Repair and Diagnosis
>>
Engine, Cooling and Exhaust
>>
Cooling System
>>
Temperature Gauge
>>
Testing and Inspection
>>
With Digital Gauges
With Digital Gauges
Fig. 7 Water Temperature Gauge Inspection:
Refer to
Fig. 7
for fuel and/or
temperature gauge
diagnosis.
