DTC 14
DTC 14
The ECU detected an open circuit
DTC 14 Vehicle Speed Sensor Diagnostic Chart:
DIAGNOSTIC CHART IMAGE
Vehicle Speed Sensor Circuit:
CIRCUIT DIAGRAM IMAGE
