Inspection & Adjustment

FRONT SUSPENSION INSPECTION AND ADJUSTMENT





Wheel Alignment (Unladen *1)
Refer to image for vehicle ride height measuring points.


*1 Fuel, radiator coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.
