Heater Core: Service and Repair

Note: Nissan does not provide a step by step removal and installation procedure for the heater core. However, as noted in the illustration, servicing the heater core requires removal of the instrument assembly. Refer to Instrument Panel, Gauges and Warning Indicators/Instrument Panel/Instrument Panel Circuit Board/Service and Repair/Procedures. Service and Repair
