LOGIC FLOW CHARTS (Monitor Sequence) < Functional check - Shift fork 2 requested but shift fork 1 movement >

WARNING: This page is about a different car, the 2015 Mitsubishi Lancer. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Monitor Sequence Logic Flow Charts (Check - Shift Fork 2 Requested But Shift Fork 4 Movement)
G09625843Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
