Disassembly And Assembly

WARNING: This page is about a different car, the 2014 Mitsubishi Outlander. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Disassembled View Of A/C Compressor Suction Hose And Liquid Pipe
G09667495Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
