Warning/Caution Labels

WARNING: This page is about a different car, the 2014 Mitsubishi Outlander. However, it is still accessible from the selected car via links, so may be relevant.

The labels indicating the precautions for handling and maintenance of SRS air bags and seat belt with pre-tensioner are attached to the locations shown in the figure. If the label is damaged or is dirty, replace with the new label.

Fig 1: Identifying Warning/Caution Labels
G09666747Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
NOTE: *: Indicates LHD vehicles. For RHD vehicles, the specified application position of label is reversed left to right
