< Vehicles Without Security Alarm Sensor >

Fig 1: Identifying Sunshade Illumination Changeover Switch Remove/Install Components (Vehicles Without Security Alarm Sensor)
G07050170Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
