Removal And Installation: Notes

WARNING: This page is about a different variant/trim than selected.
Fig 1: Exploded View Of Parking Brake Lining And Drum With Torque Specifications
G06677712Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
