Removal And Installation: Notes

WARNING: This page is about a different variant/trim than selected.

Fig 1: Water Hose And Water Pipe Replacement Components With Torque Specifications

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

Required Special Tool:
