>> A << Headlight Support Upper Panel Installation

WARNING: This page is about a different car, the 2008 Mitsubishi Lancer. However, it is still accessible from the selected car via links, so may be relevant.

After installing the headlight support upper panel, tighten the bolts shown in the illustration to the specified torques.

Fig 1: Locating Headlight Support Upper Panel Bolts
G05395027Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
Fig 2: Headlight Support Upper Panel Removal And Installation Replacement Components With Torque Specifications
G05395028Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
