Home >> Mitsubishi >> 2010 >> Lancer ES, Standard >> Repair and Diagnosis >> Engine Mechanical >> Mechanical >> Engine Intake System And Exhaust System - Lancer >> Intake Manifold >> Removal And Installation (2.0L Engine Non-Turbo, 2.4L Engine) >> Notes

Removal And Installation (2.0L Engine Non-Turbo, 2.4L Engine): Notes

Fig 1: Intake And Exhaust Replacement Components With Torque Specifications

G06671818

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
