Home >> Mitsubishi >> 2010 >> Lancer ES, Standard >> Repair and Diagnosis >> Engine Mechanical >> Cooling System (Mechanical) >> Engine Cooling -- Lancer >> Water Hose And Water Pipe >> Removal And Installation (2.0L Engine Turbo) >> Notes

Removal And Installation (2.0L Engine Turbo): Notes

Fig 1: Radiator Hose Replacement Components With Torque Specifications
G06671781Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

Required Special Tool:
