Inspection Procedure 1: The diagnostic trouble code is not set.: Notes

CAUTION: Before replacing the ECU, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

Fig 1: Diagnosis Connector Communication Circuit Diagram

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
