<< B >> Assist Link Bolt Removal

Place mating marks on the crossmember and the plate before removing the assist link bolt.

Fig 1: Removing Assist Link Bolt

G04255218

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
